NEW QUARTZ FIBERS AND COMPOSITE

VERTYS MINERAL QUARTZ

Innovative material used for metal-free structures and/or monolithics

Discover the innovation introduced by the new fibers with extremely high silica content and nanocomposite. Both materials are certified as Class IIa for permanent medical devices.

GET ADVICE FROM OUR EXPERTS

Contact us for information on pricing, usage, and technical specifications of the MINERAL QUARTZ / PLUS line.

    According to the Terms & Conditions, I consent to the processing of my personal data.

    Discover the innovation of MINERAL QUARTZ for your final restorations

    • Fast, simple, and ultra-lightweight
    • Compatible with CAD-CAM technologies
    • Suitable for exposure to soft tissues
    • Fracture resistance up to 3200N

    ASK A SPECIALIST FOR MORE INFO

    MINERAL QUARTZ (bar)

    The ideal solution for limited space cases,
    compatible with your milling machine and 3D printing,
    suitable for immediate and/or final loads, workable directly in the oral cavity,
    perfect for the Dental Technician or the Dental Clinic.

    MINERAL QUARTZ PLUS (bundle)

    The ideal solution for limited space cases with extensions up to 2 cm,
    designed to pair with 3D printing,
    immediate and/or final loads in record time,
    perfect for the Dental Technician.

    BAR – MINERAL QUARTZ

    The Bar is mainly used as a sub-structure in definitive Implant Bridges or for Immediate Loading. The Quartz Fiber bar can be “completed” with:

    Ideal for Dental Labs and Clinics

    Request a Quote!

    Uses of Vertys Mineral Quartz (Bar)

    • IMMEDIATE OR DEFINITIVE LOADING
    • SUB-STRUCTURE FOR IMPLANT BRIDGES
    • OVERDENTURES
    • SUB-STRUCTURE FOR TEMPORARY BRIDGES
    • BAR SUB-STRUCTURE FOR FULL DENTURES AND/OR ATTACHMENTS

    Main Features of Vertys Mineral Quartz (Bar)

    • Composed of 30% quartz fibers and 70% composite matrix
    • Diameter: 8 mm, Length: 10 cm
    • Available in 2 shades: pink (for users of commercial teeth) or dentin (for those who want to create monolithic restorations in resin or injected composite)
    • Before light-curing, the bar can be manually shaped into any form
    • Can be modified in thickness even after light-curing, using Mineral Quartz Flow in a 3g syringe (dentin or pink shade)
    • Shaping is done using the burs from the Vertys Polish Kit >
    • Covered with a thin transparent film to keep hands clean during handling (especially intraorally)
    • Compatible with all acrylic
    Request the Work Protocol PDFDiscover the product

    Main Advantages of Mineral Quartz (Bar)

    CREATION OF A DEFINITIVE BAR IN 10 MINUTES*

    LOAD-BEARING STRENGTH UP TO 1800N

    COMPATIBLE WITH MILLED AND 3D-PRINTED COMPONENTS

    NO SHAPE LIMITATIONS

    PERFECT FOR INTRAORAL USE

    WISP – MINERAL QUARTZ PLUS

    The “Ciuffo” is mainly used as a monolithic structure in implant bridges. It is available in a dentin shade for layering with pink composite, or in pink when combined with traditional commercial teeth.

    Ideal for Dental Technicians

    • The composite-based Quartz Plus is 3D-printable and acts as a supporting structure (can be repaired intraorally with composite)
    • Possibility to rebase milled PMMA shells
    • The entire aesthetic portion is completed using Vertys Mineral Composite >
    • The pink Quartz PLUS serves as the supporting structure when using commercial teeth
    Request a Quote!
    Request the Work Protocol PDFDiscover the product

    Applications of Vertys Mineral Quartz PLUS (Bundle)

    • MONOLITHIC IMPLANT BRIDGE (TEETH + TISSUE)
    • IMPLANT BRIDGE WITH STOCK TEETH + PINK QUARTZ TISSUE
    • SUPPORTING FRAMEWORKS
    • FABRICATION OF COUNTER-BARS
    • FIXED BRIDGES
    • MARYLAND

    Key Features of Vertys Mineral Quartz PLUS (Bundle)

    • Presented in a “bundle” form, composed of 70% quartz fibers and 30% composite matrix
    • Approximately 1.5 cm wide and 10 cm long
    • Before light-curing, the bundle must be pressed using the Furbo Composite > or Furbo Plexi > flask
    • After light-curing, the piece can be freely modified in both thickness and shape
    • Aesthetics can be adjusted at any time using the Vertys Quartz Flow liquid quartz syringe and the composites from the Vertys Mineral > line
    • Available colors: dentin A2 and pink
    • Primarily used with transparent silicones >: Vertys Medium Glass A+B (50 Shore) and Vertys Heavy Glass cartridge silicone (70 Shore)

    Main Advantages of Mineral Quartz PLUS (Bundle)

    FINAL MONOLITHIC RESTORATION IN 60 MINUTES*

    FRACTURE LOAD RESISTANCE UP TO 3200N

    POSSIBILITY TO WORK WITH MINIMAL THICKNESSES

    COMPATIBLE WITH METALS (OVERDENTURE ON ATTACHMENTS)

    VERY LOW SPECIFIC WEIGHT BUT INCREDIBLE FRACTURE RESISTANCE

    Which Product Is Right for You?

    Let’s take a closer look at the two materials by comparing their technical specifications.

    MINERAL QUARTZ (Bar)

    Elastic Modulus 8500 MPa

    Filament Diameter 15 µm

    Water Absorption < 1%

    Compressive Strength 1800N

    Flexural Strength > 420 MPa

    Radiopacity YES

    Specific Weight 2.0 g/cm³

    Tex 280

    Diametral Tensile Strength 80 MPa

    MINERAL QUARTZ PLUS (WIsp)

    Elastic Modulus 7500 MPa

    Filament Diameter 15 µm

    Water Absorption < 1%

    Compressive Strength 3200N

    Flexural Strength > 420 MPa

    Radiopacity YES

    Specific Weight 1.6 g/cm³

    Tex 280

    Diametral Tensile Strength 80 MPa

    Request a Quote!

    FAQ BAR

    How far can I extend in cantilever?

    Up to a maximum of 1 cm.



    Do I always need to use a primer?

    Yes, Mineral Universal Bond.



    Can it be combined with 3D printed / milled Class materials?

    Yes, by sandblasting and using Mineral Universal Bond.



    Can it be combined with standard commercial teeth?

    Yes, with proper mechanical retention and Mineral Universal Bond.



    What is the minimum thickness to maintain?

    Around the abutments, maintain 1.5 mm.



    Which opaques are recommended for thin layers?

    Vertys Mineral Opak Gold!



    What material can be used for additions or modifications to the bar?

    The 3g Vertys Mineral Quartz Flow syringe (pink or dentin shade)!



    Can it be repaired once cut?

    No, once the fibers are broken, the bar cannot be repaired.



    What are the minimum light-curing requirements?

    LED light with at least 450 nm wavelength.



    Is there a maximum temperature the material can withstand without deforming?

    Maximum 60 °C.

    Speak with an Expert

    FAQ BUNDLE

    How far can I extend in cantilever?

    Up to a maximum of 2 cm.



    Do I always need to use a primer?

    Yes, Mineral Universal Bond.



    Can it be combined with 3D printed / milled Class materials?

    Yes, by sandblasting and using Mineral Universal Bond.



    Can it be combined with standard commercial teeth?

    Yes, with proper mechanical retention and Mineral Universal Bond.



    What is the minimum thickness to maintain?

    The bundle, being monolithic, does not require minimum thickness.



    What material can be used for additions or modifications?

    The 3g Vertys Mineral Quartz Flow syringe (pink or dentin shade)!



    Can it be repaired once cut?

    No, once the fibers are broken, the bundle cannot be repaired.



    What are the minimum light-curing requirements?

    LED light with at least 450 nm wavelength.



    Is there a maximum temperature the material can withstand without deforming?

    Maximum 60 °C.

    Speak with an Expert

    The 6 Steps of Our Operating Protocol

    Design with CAD or traditional wax modeling

    3D printing of the models and the provisional

    Recording the morphology of the functionalized provisional using the Furbo flask and silicones

    Structure fabrication

    Injection of Vertys Monomassa acrylic resin or Vertys Mineral composite

    Incisal cut-back and injection of Vertys Mineral enamel

    Characterization with the composites from the Vertys Mineral Pink > line or injection of the acrylic resin Vertys Prothesis Excel >

    Glazing and final polishing
